Custom Grid Configurations
Grid layouts are custom-proportioned to fit exact opening heights and widths, maintaining visual symmetry across all facade elevations.
Timeless Design & Thermal Engineering
Bring Classic Architectural Character to Modern High-Performance Openings
Architects and developers worldwide specify Georgian bar windows to give modern structural glazing a distinctive, period-inspired divided light appearance without sacrificing thermal performance or weather tightness.
At Tejjsons, our aluminium window systems feature custom Georgian grid bars precision-sealed directly inside the hermetically insulated glass unit (IGU). This encapsulated construction ensures the internal decorative grid remains completely dust-free, maintenance-free, and protected against environmental degradation throughout its multi-decade service life.
- Internal sealed grid bars eliminate cleaning, polishing, and exterior wear
- Double and triple glazed options with argon gas fill and Low-E thermal coatings
- 6063-T5/T6 architectural-grade extruded aluminium profiles for ultimate stability
- Customizable grid spacing, bar width, and full spectrum RAL powder coating or anodizing
Key Technical Advantages
Why International Specifiers & Importers Partner with Tejjsons
We design, fabricate, and test each window configuration around your precise architectural drawings and regional building code requirements.
Precision CNC Assembly
Internal bars are locked in alignment using internal mechanical brackets to ensure vibration-free, noise-free performance in high wind zones.
Thermal & Acoustic Barrier
Integrated with thermally broken aluminium frames and multi-chamber EPDM gaskets to reduce HVAC cooling loss and external noise transmission.
Export-Grade Shipping
Crated in reinforced wooden frames with corner protection and A-frame glass protection designed for long-distance multi-modal sea freight.
Manufacturing Benchmark
Engineering Specifications for Georgian Bar Window Systems
Baseline production parameters for global export projects. Final frame depth, glazing cavity, and hardware schedules are configured per project drawing sign-off.
| Parameter | Standard Manufacturing Specification | Project Engineering Benefit |
|---|---|---|
| Aluminium Alloy Grade | 6063-T5 / 6063-T6 Architectural Grade Extrusions | Ensures precise corner joints, high structural wind-load resistance, and long-term frame rigidity. |
| Glazing Build-Up | Double Glazed Units (5mm-12A-5mm or 6mm-16A-6mm) Toughened / Laminated | Delivers superior acoustic attenuation and thermal U-value control tailored to hot, mixed, or temperate climates. |
| Georgian Bar Integration | Internal Sealed Profile Grid (18mm, 25mm, or 40mm width options) | Permanently protected inside the sealed glass cavity; prevents dirt buildup and weather damage. |
| Surface Finishing | Qualicoat-compliant Powder Coating (60–80 µm) or Anodizing (15–25 µm) | Resists UV degradation, chalking, and salt-spray corrosion in demanding tropical or coastal environments. |
| Compatible Window Types | Casement, Tilt & Turn, Fixed Architectural Lite, Sliding & Bi-Fold Systems | Allows unified design continuity across all exterior window and door openings within the project. |
| Hardware & Seals | European Multi-Point Locking Systems & Continuous EPDM Weather Gaskets | Guarantees air-tight compression sealing, burglary resistance, and smooth mechanical operation. |
Versatile Application Scope
Ideal Glazing Solutions for Luxury Residential & Commercial Development
From classic Mediterranean villas and colonial townhouses to upscale boutique hotels and themed commercial developments, Georgian bar glass adds unmistakable character.
- Luxury Private Estates & Custom Villas
- Boutique Hotels, Resorts & Clubhouse Facilities
- Heritage Restoration & Urban Renewal Projects
- Aesthetic Cafes, Restaurants & Flagship Retail Stores
Our in-house design engineering team produces detailed CAD shop drawings for approval prior to production, ensuring seamless site installation for contractors and facade installers.
Technical FAQ
Frequently Asked Questions by Specifiers & Importers
Key answers regarding our glass with Georgian bar systems, customization options, and global export shipping process.
Georgian bars are decorative grid elements mounted internally within double glazed glass units. They divide large glass panels into classic smaller geometric panes, reproducing traditional Georgian and colonial architectural styles while maintaining modern thermal efficiency, soundproofing, and structural strength.
No. Tejjsons manufactures Georgian bars sealed directly inside the insulated double-glazed cavity. Because the grid is completely encapsulated between glass panes, both exterior and interior glass surfaces remain flat, making them effortless to clean with zero risk of bar discoloration or damage.
Internal Georgian bars are factory-sealed inside the double-glazed unit during assembly to ensure hermetic insulation. Therefore, individual grid bars cannot be manually removed. If a design change is required, a replacement double-glazed unit can be supplied to drop directly into the existing aluminium frame.
We supply Georgian bars across all our major aluminium frame families, including casement, tilt and turn, bifold, sliding, and fixed arched windows. Bars can be powder-coated in any custom RAL color to match or contrast with the main frame profiles.
All international orders are packaged in reinforced, steel-strapped wooden crates lined with moisture barriers. Glass panels and framed assemblies are secured on custom A-frame racks with heavy-duty corner guards to guarantee safe delivery via sea container freight to global destination ports.
Require Custom Glazing for Your Upcoming Project?
Submit your architectural drawings, elevation schedules, or opening dimensions for a preliminary engineering review and competitive export quotation.
